Description

Location: Germany, Baden-Württemberg Southwest

Condition: Used

Manufacturer: Alzmetall

Model: 30/S

Year of construction: 2004

For sale: a used Alzmetall ALZSTAR 30/S pillar drill, manufactured in 2004, from German quality production.

Technical data:
Machinability in steel E335 (St 60): 30 mm
Thread cutting performance in steel E335: M16
Thread cutting performance in cast iron EN-GJL-200: M20
Spindle mount: MK 3
Spindle stroke / Z-axis stroke: 140 mm
Overhang / Spindle to column distance: 293 mm
Column diameter: 115 mm
Table size / clamping surface: 514 x 360 mm (also specified as 515 x 360 mm on the product page)
T-grooves: 2 x 14 x 224 mm
Spindle/Table clearance min./max.: 132 / 724 mm
Drive: continuously variable, mechanical variator
Spindle speed range: 225–4300 rpm
Motor power at 750 / 1500 rpm: 1.0 / 1.6 kW
Machine height: approx. 1790 mm
Machine weight: approx. 260 kg

The machine can be inspected by appointment.
Changes and errors in the technical data and information as well as prior sale reserved!

For sale is a used Alzmetall ALZSTAR 30/S column drill press, manufactured in 2004, a product of German quality engineering.

Technical specifications:
Drilling capacity in E335 steel (St 60): 30 mm
Thread cutting capacity in E335 steel: M16
M20
Spindle chuck: MK 3
Quill stroke / Z-axis stroke of the spindle: 140 mm
Width of column: 62 mm
Column diameter: 115 mm
Table size / clamping surface: 514 x 360 mm (also stated as 515 x 360 mm on the product page)
T-slots: 2 x 14 x 224 mm
Spindle/table distance min./max.: 132 / 724 mm
Transmission: stepless, mechanical variator
Spindle speed range: 225–4300 rpm
Motor power at 750 / 1500 rpm: 1.0 / 1.6 kW
Machine height: approximately 1790 mm
Machine weight: approx. 260 kg

The machine can be viewed by appointment.
We reserve the right to make changes and corrections to the technical data and specifications, and to sell the item in the meantime!
