Description

Location: Germany, Baden-Württemberg Southwest

Condition: Used

Manufacturer: DOOSAN-PUMA

Model: LYNX 2100 LSYB

Year of construction: 2019

Operating hours: 9000

For sale is a powerful and versatile CNC turning/milling center Doosan LYNX 2100 LSYB, built in 2019, with approximately 9,000 operating hours.

Technical data

Manufacturer: Doosan Machine Tools
Model: LYNX 2100 LSYB
Control: Doosan-FANUC i
Machine type: CNC turning/milling center
Year of construction: 2019
Operating hours: approx. 9,000 h

Work area

Max. turning diameter: approx. 300 mm
Max. length of the beam: approx. 510 mm
Diameter around bed: approx. 600 mm
Circumference over cross-rails: approx. 400 mm
Rod diameter: approx. 65 mm

Travelling distances

X axis: approx. 205 mm
Y-axis: approx. 105 mm / ±52.5 mm
Z axis: approx. 560 mm
Travel distance of the counter spindle / B-axis: approx. 560 mm

Main spindle

Spindle rotation speed: up to approx. 4,500 rpm
Spinning power: approx. 15 kW
Spindle nose: ASA A2-6
Spindle bore: approx. 76 mm
Rod diameter: approx. 65 mm
C-axis: present

Counter spindle

Max. speed: approx. 6,000 rpm
Power: approx. 5.5 kW
C-axis: present
Automatic workpiece transfer between the main spindle and the counter spindle

Tool Revolvers

Revolver: BMT45P
Tool stations: 12
Powered tools: available
Max. rotational speed of driven tools: approx. 6,000 rpm

Quick passage

X axis: approx. 30 m/min
Z axis: approx. 36 m/min

Dimensions and weight

Machine weight: approx. 4,200 kg
Dimensions L × W × H: approx. 2,880 × 1,710 × 1,920 mm

The machine can be viewed by appointment.
Changes and errors in the technical data and information as well as prior sale reserved!

A high-performance and versatile Doosan LYNX 2100 LSYB CNC turning/milling centre, manufactured in 2019, with approximately 9,000 operating hours, is for sale.

Technical specifications

Manufacturer: Doosan Machine Tools
Model: LYNX 2100 LSYB
Control system: Doosan-FANUC i
Machine type: CNC turning/milling center
Year of manufacture: 2019
Operating hours: approx. 9,000 h

Working range

Max. turning diameter: approx. 300 mm
Max. turning length: approx. 510 mm
Swivel diameter over bed: approx. 600 mm
Swivel diameter over cross slide: approx. 400 mm
Bar passage: approx. 65 mm

Travel ranges

X axis: approx. 205 mm
Y axis: approx. 105 mm / ±52.5 mm
Z-axis: approx. 560 mm
Travel range of counter-spindle / B-axis: approx. 560 mm

Main spindle

Spindle speed: up to approx. 4,500 rpm
Spindle power: approx. 15 kW
Spindle nose: ASA A2-6
Spindle bore: approx. 76 mm
Bar passage: approx. 65 mm
C-axis: fitted

Counter spindle

Max. speed: approx. 6,000 rpm
Power: approx. 5.5 kW
C-axis: fitted
Automatic workpiece transfer between main and counter spindles

Tool turret

Turret: BMT45P
Tool stations: 12
Powered tools: available
Max. speed of powered tools: approx. 6,000 rpm

Rapid traverse

X axis: approx. 30 m/min
Z-axis: approx. 36 m/min

Dimensions and weight

Machine weight: approx. 4,200 kg
Dimensions L × W × H: approx. 2,880 × 1,710 × 1,920 mm

The machine can be viewed by appointment.
We reserve the right to make changes and corrections to the technical data and specifications, and to sell the machine in the meantime!
