CNC sliding headstock lathe TSUGAMI HS2075AX, year 2012

CNC sliding headstock turning/milling centre with B-axis
Operating hours: 7200
Control system: Fanuc 31i-A
Machining length: max. 250 mm
Number of controlled axes: 7 axes and max. 5 axes simultaneously
B-axis: 0°-130° freely programmable
Rod passage: Ø 3 mm to max. Ø 20 mm
Drive power main spindle: 3.7 kW
Drive power counter spindle: 2.2 kW
Main spindle speed: 10,000 rpm
Counter spindle speed: 10,000 rpm
C-axis: Main and counter spindle
Number of linear supports: 2 pieces
Total number of tools: 35 pieces
Dimensions (LxWxH) in mm: 2,110×1,200×1,885
Weight: 3,300 kg
Conversion from long to short turning
Deep hole drilling stations
NAKANISHI high-speed spindle
Rear slide with Y-axis
Cross drilling rear side
Chip conveyor
Fire extinguishing system

FMB bar loader Minimag 20, year 2012

The machine can be inspected under power by appointment.
Changes and errors in the technical data and information as well as
Subject to prior sale!
