CNC short turning lathe Goodway SW 42

FANUC Series 31i Model B, 10.4″, coloured
12 months warranty on all FANUC parts (in single-shift operation)
Operating hours: 0
Short turning version, with movable headstock,
Hydraulic clamping system, suitable for Hainbuch SK 52
7 axes (X/Z /Y/C/Z2/X2/C2),
Rod Ø max. 42 mm
Turning length max. 110 mm
Main spindle, max. speed 6,000 rpm, C-axis,
FANUC-Motor, hydraulische Spannung, 5,5kW 100%ED, 7,5kW 30 min ED
Counter spindle, max. speed 6,000 rpm, C-axis,
FANUC-Motor, 3,7kW 100%ED, 5,5kW 30 min ED
5-fold tool holder, 20x20mm
5-position drill holder,
4 cross drilling units, driven, (2 pcs. modular), max. speed 6,000 rpm

FANUC-Motor, 1,4kW 100%ED, 1,88kW 30 min ED
4 positions for back machining / driven, max. speed 5,000 rpm
FANUC-Motor, 0,75kW 100%ED, 1,0kW 30 min ED
Parts conveyor belt
Oil cooler unit
Coolant sump
Chip conveyor, hinged belt type
Manuals Operation/Programming/Electrical/Spare Parts
Machine dimensions: approx. 2950 x 1550 x 2150 [mm] Machine weight: approx. 3300 [kg]

The machine can be inspected by electricity by appointment.
Subject to alterations and errors in the technical data and information as well as prior sale!
